SmartCode system from DeVilbiss makes it fast and easy to access sleep therapy data -- whether it is for yourself, for your job, or for your doctor. SmartCode is an alpha-numeric code that is shown on the display of the IntelliPAP. Your code can be phoned in to your doctor, emailed to your job, or you can use it yourself. The characters and sequences in your SmartCode contain vital sleep therapy usage data in an encrypted form. Enter the code into the SmartCode Report Generator at IntelliPAP.COM and you'll have instant access to your therapy data in easy to read reports that can be saved or printed. No external software or data card is needed, everything is always available right on your machine!
Most people find it is easier to fall asleep with a lower therapy pressure that gradually increases to the full prescribed pressure setting over time. The IntelliPAP's ramp comfort feature does this. Ramp time can be set from 0-45 minutes (in 5 minute increments); and If you wake up in the night and have trouble falling back to sleep, the ramp can be reinitiated with the simple push of a button.
GENERAL SPECIFICATIONS | |
---|---|
Manufacturer | Drive DeVilbiss |
Part Numbers | DV51D |
HCPCS Codes | E0601 |
GTIN/UPC Codes | 00885304001935 |
In The Package | IntelliPAP Standard CPAP Machine, Travel Bag, Filters (Reusable Foam & Ultra Fine), 6-Foot Tube, Printed Users Manual, Power Cord, & Printed User Manual |
PHYSICAL DETAILS | |
---|---|
Dimensions | CPAP Machine = 6.5 x 7.0 x 4.2 Inches, (Approximate) |
Weight | CPAP Machine = 2.75 lbs |
PAP MACHINE SPECIFICATIONS | |
---|---|
Therapy Modes | CPAP |
Pressure Range | 3-20 CM H2O |
Tubing Compatibility | All 22mm Standard Tubing |
Ramp | 0 to 45 minutes (5-min increments) |
Ramp Start | 4 to CPAP Pressure (User adjustable) |
Leak Compensation | yes |
Auto On/Off | yes |
Sound Levels | 26 dBa (Average) |
Oxygen Compatibility | Compatible |
THERAPY DATA | |
---|---|
Data Included | Onboard |
AC (WALL) POWER SPECIFICATIONS | |
---|---|
AC Power Input | 100-240 V, 50-60 Hz |
Power Cord Length | 8 Feet |
DC (MOBILE) POWER SPECIFICATIONS | |
---|---|
DC Power Input | 10.4 to 15V DC |
Flex Spending HSA FSA Eligible
